Reverse Engineering PCB Board Side Road capacitor installation

When reverse engineering PCB board, Side road capacitor usually play the role of decrease the transient power supply requirement on the power module beside the high frequency component. Normally aluminum capacitor and tantunum capacitor is more suitable for side road. And its value depends on the on transient current requirement on the PCB, normally 10-470LF, if there are lots of integrated circuit , high speed switch on/off and power supply with long lead, then great capacitance capacitor should be chosen.

Decoupling Capacitor installation

1> connect 10-100LF electro on the power supply output terminal, use 100LF is better if possible;

2> fundamentally all the integrated circuit chip should be board reverse engineering a 0.01pf ceramic capacitor on the PCB, if there is not sufficient space on the PCB, one piece of 1-10PF tantalum capacitor on every 4-8 piece of chips;

3> as for the component with great change when power off the supply or with weak capability to resist noise, such as RAM, ROM memorizer, decoupling capacitor should be directly among the power track and grounding track;

4> the capacitor lead shouldn’t be too long especially there shouldn’t be any lead on the side of high frequency capacitor;

5> since there is contact, relay and press button in the PCB which will cause great discharge current must apply RC circuit to absorb the discharge current, and R is 1-2K, C is 2.2-47LF;

6> CMOS has high input impedance and quite sensible, so it is unused terminal should be connected to grounding or anode side.
