Copy Locked ST62T15C Microprocessor OTP Eprom Firmware

Copy Locked ST62T15C Microprocessor OTP Eprom Firmware after attack its security fuse bit protection over the microcontroller ST62T15C and then extract embedded program from MCU flash memory;

The ST6215C, 25C devices are low cost members of the ST62xx 8-bit HCMOS family of microcontrol- lers, which is targeted at low to medium complexity applications. All ST62xx devices are based on a building block approach: a common core is sur- rounded by a number of on-chip peripherals.

The ST62E25C is the erasable EPROM version of the ST62T15C, T25C devices, which may be used during the development phase for the ST62T15C, T25C target devices, as well as the respective ST6215C, 25C ROM devices.

OTP and EPROM devices are functionally identi- cal. OTP devices offer all the advantages of user programmability at low cost, which make them the ideal choice in a wide range of applications where frequent code changes to cloning electronic circuit board gerber file, multiple code versions or last minute programmability are required. The ROM based versions offer the same function- ality, selecting the options defined in the programmable option bytes of the OTP/EPROM versions in the ROM option list (See Section 12.6 on page 97).

The ST62P15C/P25C are the Factory Advanced Service Technique ROM (FASTROM) versions of ST62T15C,T25C OTP devices. They offer the same functionality as OTP devices, but they do not have to be programmed by the customer (See Section 12 on page 91).

These compact low-cost devices feature a Timer comprising an 8-bit counter with a 7-bit program- mable prescaler, an 8-bit A/D Converter with 16 analog inputs and a Digital Watchdog timer, mak- ing them well suited for a wide range of automo- tive, appliance and industrial applications.
