PCB Reverse Engineering, Cloning & Copy Services
Send us a physical circuit board and we return a complete, verified design package — Gerber files, full schematic, bill of materials and fabrication data. Since 2011 we have recovered board designs for equipment owners, repair workshops and manufacturers worldwide.
Three Ways to Reproduce a Board
PCB Reverse Engineering
Recover the complete design from a manufactured board: every copper layer, the schematic, the BOM and a netlist report proving the data matches the board.
PCB reverse engineering service →
PCB Cloning
Rebuild the same board rather than a substitute: bare-board geometry, copper routing, matched components and an optional tested prototype.
PCB Copy
Fabrication-ready Gerber and drill files taken from a sample board — the fastest, lowest-cost route to replacement bare boards.
What You Receive
- Gerber files, all layers (RS-274X) — manufacturing at any PCB fabricator
- Full schematic diagram (PDF, editable source on request) — analysis, maintenance, redesign
- Bill of Materials (Excel / CSV with part numbers) — sourcing components
- Pick-and-place file (CSV) — automated assembly
- Assembly and fabrication drawings (PDF) — production reference
- Netlist verification report (PDF) — proof the data matches the physical board
How a Project Runs
- Send photos of both sides of the board. We confirm layer count, board size and component density, then return a fixed price.
- Fixed quote, usually within one business day. No hourly surprises — the price is fixed before any work starts.
- Layer scanning and schematic capture. Each copper layer is imaged and re-drawn, then converted into a readable circuit diagram net by net.
- Verification against the physical board. The extracted netlist is checked with continuity testing, so the data is proven rather than assumed.
- Delivery — and optionally a rebuilt prototype. You receive the full data package; if you need confidence before production, we fabricate and test one board.
Why Customers Send Us Their Boards
- Reverse engineering PCBs full time since 2011, with boards shipped in from customers around the world.
- Experience across power electronics, motor drives, ECU/TCU automotive controllers, industrial PLC boards, communication modules and consumer electronics.
- Every deliverable is verified against the physical board before it leaves our desk; the netlist report is included as standard.
- Strict confidentiality — we work under NDA on request and never reuse or resell customer design data.
Get a Fixed Quote
Send photos of both sides of the board and we will reply with a fixed price and schedule — no obligation.
Email info@circuitengineer.com or use our contact form. Prefer to ship the board first? We confirm receipt and report our assessment before any work begins.
Tel 86-755-21019972 · WhatsApp 86-189 3864 0277 · Skype circuitengineer
Also see our manufacturing capability and frequently asked questions.
