Printed Wiring Board Reverse Engineering Software

The newly launched printed wiring board reverse engineering software name PowerPCB 5.0 from INNOVEDA can satisfy all kinds of requirement, this system includes BLAZEROUTER HSD which is base upon the printed wiring board shape and principle for high speed reverse engineering, it allow to limit the terms according to high speed reverse engineering, include the minimize and maximum length, matched length and differential PAID to layout the printed wiring board automatically. These limited terms can install any places in the system, BLAZEROUTER HSD can Reverse Engineering PCB according to these principles automatically. As a result of that, it can install and protect the critical circuit topology to ensure all the critical signals can be connected in correct consequence.

This tool also provide the intersect layout editor for those reverse engineering engineer who wish to layout manually, and tremendous dedicated support for the network generated from those restricted terms. The new fast intersect layout editor has multiple reverse engineering rule checking mode and new layout editing functions. Engineer can add “Z” shape socket automatically to look for differentiation, monitor the track length or reverse engineering the printed wiring board according to specific reverse engineering rules. Consequently engineer will be more readily to layout with high density and layout as much track density as possible on the least layer count.

Besides, this PCB board reverse engineering tool provide graphic descriptive feedback function, and can indicate the impact on other networks when layout the printed wiring board. In the past, it is quite difficult for reverse engineering engineer to understand the negative impact on other network when the modification of critical network. BLAZEROUTER HSD can describe these impact which wouldn’t be reveal in pictorial form by different color and lightness. Which can help reverse engineeringer to understand each potential impact on the printed wiring board reverse engineering.
