PCB Copy Accurary

PCB Copy Accurary depends on two aspects, one is the accuracy of the software which applied for this service process, one for the original image accuracy scanning from it.

Those companies who provide PCB copying service in the current market possess broad variety of precision technical capacity, and some of them have lower accuracy as a result of absence of high technical ability, but some of them can reach 1mil accuracy;
There is no restriction on precision if the software apply 32-bit floating point, so the most important thing depends on the accuracy of the original scanned image, for example, if with 100 million pixels, the picture can be washed 5-inch photos, but if we want it to wash into a 20-inch photos, it simply can not see, so for a high precision circuit board is, Choosing a higher DPI is necessary and critical when scaning the PCB circuit board which will help to obtain an good solution PCB Copy pictures.

The definition of DPI is quantity of points per inch. It simply stand for the distance between two points of the scanned image is 1mil, so if DPI is 400, then the distance between two points on the image is 1000/400 = 2.5 mil, that means the accuracy is 2.5mil.

This is the most scientific measurement way, although some people claim the accurary can below 1mil, it is a prerequisite. In fact, the PCB Copy accurary largely depends on the original image accuracy.

To sum up, DPI value setting on the scanning machine should be determined by the requirement level of accurary of PCB which is ready to be Copied, for instance, line spacing of mobile phone circuit board usually below 1mil, then the value of DPI need to be set at more than 1000 . Scanner on the market today can satisfy this condition.
But it is hard to say the higher DPI being set, the better PCB Copy accuracy can be achieved.

Since higher DPI is too large to install and process in the hardware enviroment which has much higher requirement on the hardware, so the specific settings of DPI value should be adjustable according to specific PCB and their corresponding requirement. For the Printed Circuits Boards with general accuracy requirement need to generally use 400DPI is enough.
